Open VIP-PCM pharmaceutical shipper with payload chamber and PCM panels

Tempk pharmaceutical passive shipper range

VIP-PCM شاحن الطرود الصيدلانية

A passive temperature-controlled packaging system combining protected vacuum insulation panels (كبار الشخصيات) with temperature-specific phase change materials (PCMS). Tempk configures the payload chamber, نقطة مرحلة PCM, conditioning method and packout sequence for pharmaceutical, biologic and clinical-supply lanes.

شكل المنتج Passive temperature-controlled parcel shipper with protected VIPs and conditioned PCMs
Common payload planning Approximately 3–30 L usable payload volume; custom chambers available
Temperature programs 2-8 درجة مئوية, 15–25 °C controlled room temperature (إنبوب أشعة القطب السالب) and sub-zero programs use separate qualified configurations
Duration targets 48, 72, 96 أو 120 hours can be evaluated against the defined lane profile

A lane-specific passive shipper for high-value healthcare parcels

Inside the corrugated carton, protected VIPs and conditioned PCM panels surround a defined payload cavity. Separate configurations can be developed for refrigerated, درجة حرارة الغرفة التي تسيطر عليها (إنبوب أشعة القطب السالب) or frozen transport. Qualified duration applies only to the tested payload, إجراء التكييف, ambient profile and route.

More usable payload space

Protected VIPs provide high insulation with thinner walls than many conventional systems, preserving payload volume.

Temperature-specific PCM control

The PCM phase point and conditioning state are selected around the medicine's allowable temperature range.

Repeatable packout geometry

Dedicated PCM positions, a defined payload chamber and packing instructions help operators reproduce the tested configuration.

Seasonal protection

A balanced PCM arrangement can be developed for summer, winter or combined ambient profiles, including freeze-sensitive 2–8 °C products.

Qualification inputs

Tempk can support component specifications, مخططات الحزمة, تعليمات التكييف, samples and testing inputs for the buyer's qualification program.

تفاصيل المنتج

ماركة Tempk
اسم المنتج VIP-PCM شاحن الطرود الصيدلانية
نوع النظام Passive temperature-controlled parcel shipper
Outer container Corrugated shipping carton selected for payload weight, تكديس, route handling and required print
العزل Protected vacuum insulation panels arranged around the payload chamber; panel construction is selected by project
VIP thickness planning Approximately 10–25 mm is a common project starting range; final thickness follows thermal and mechanical design
VIP conductivity reference Centre-of-panel values can be about 0.004 ث/(م·ك); final design uses supplier-declared aged, edge-adjusted and assembly-level data
Thermal storage medium Rigid or flexible PCM panels selected by phase-change point, heat capacity, form and conditioning requirement
حجم الحمولة الصالحة للاستخدام Approximately 3–30 L; custom smaller and larger configurations are available
Temperature programs Separate configurations can be developed for 2–8 °C, 15–25 °C controlled room temperature (إنبوب أشعة القطب السالب) and sub-zero products; each uses its own PCM and conditioning procedure
Duration planning Qualification targets of 48, 72, 96 أو 120 hours are available for evaluation; no duration applies until the complete packout is tested
Ambient profiles صيف, winter and combined route profiles selected from the buyer's lane risk and qualification protocol
Payload configurations Minimum and maximum payload conditions defined for qualification and routine packout control
مراقبة درجة الحرارة Optional data-logger pocket, sensor-location guide and shipment record label
Interior options Payload carton, المقسمات, توسيد, secondary containment and tamper-evident features
إنهاء Defined lid orientation, carton tape pattern and optional security seal
التخصيص أبعاد الحمولة, هندسة VIP, PCM phase point and mass, تكييف SOP, الطباعة, تسميات, logger location and kit packing
دعم المؤهلات Samples and technical inputs can support design qualification, operational qualification and performance qualification (دق/أوك/بق), route studies or ISTA thermal testing. Approval remains specific to the tested configuration

حيث يناسب أفضل

اللقاحات والبيولوجية

Supports passive parcel programs where temperature stability, freeze protection and documented packout control are required.

Specialty and temperature-sensitive medicines

Provides configurable 2–8 °C or 15–25 °C transport for high-value prescription products and specialty therapies.

Clinical-trial supplies

Helps standardize investigational-product shipments between depots, المواقع, laboratories and authorized recipients.

Diagnostic reagents and test kits

Protects temperature-sensitive kits, controls and reagents within the limits defined by their manufacturer.

Pharmaceutical samples and stability materials

Provides a compact format for validated samples, retained materials and controlled transfers between facilities.

Laboratory and healthcare materials

Can be configured for permitted biological or diagnostic contents when the sender provides the required primary and secondary packaging and follows applicable dangerous-goods rules.

كيفية التخطيط للحزم

Define the shipment profile

تأكد من حدود درجة حرارة المنتج, أبعاد الحمولة والكتلة, الحد الأدنى والحد الأقصى للأحمال, وقت العبور, route handoffs and monitoring needs.

Select the qualified configuration

Use the specified carton, VIP set, PCM type and quantity, payload components and sensor position for the season and lane.

Condition the PCM

Follow the approved time and temperature process, including any required tempering step before loading.

Inspect and assemble

Check every VIP for damage, then install the base, frame and PCM panels in the documented orientation. Never cut, fold or puncture a VIP.

Load the payload and monitor

Place the conditioned product, secondary containment and data logger in their defined positions and control harmful voids.

إغلاق والتسمية

Fit the top components, close the carton with the specified tape or seal pattern and apply required labels.

Record and release

Document component lots, تكييف, pack time and logger details before release under the buyer's approved procedure.

دعم التخصيص

Payload chamber

Match vial cartons, حزم الدواء, مجموعات سريرية, payload mass and minimum or maximum load conditions.

VIP insulation layout

Adjust panel dimensions, سماكة, حماية الحافة, corner treatment and protective frame without cutting panels during packing.

PCM configuration

Select phase-change point, شكل لوحة, كمية, placement and conditioning instructions for the target range and ambient profile.

Packout controls

Add color coding, numbered components, تحميل الرسوم البيانية, sensor guides and shipment record labels for operator consistency.

التغليف الخارجي

Specify corrugated board grade, مطبعة, handling marks, إغلاق واضح العبث, courier limits and return-shipping needs.

Qualification package

Plan prototypes, مواصفات المكونات, عينات الاختبار, ملامح الصيف والشتاء, minimum and maximum loads and change-control information.

تعليمات التعامل

Store cartons, VIP assemblies and PCM components in a clean, جاف, controlled area. قبل الاستخدام, verify the system size and seasonal configuration, then inspect every VIP for punctures, تخفيضات, crushed edges or loss of rigidity. Do not use a damaged panel.

Condition each PCM component according to the approved standard operating procedure. Control and record the required time, temperature and any tempering step; visual appearance alone does not confirm readiness.

Assemble the documented configuration. Keep PCM orientation, تخليص الحمولة, الحد الأدنى والحد الأقصى للحمل, الاحتواء الثانوي, cushioning and data-logger position consistent with the tested packout. Prevent direct contact between very cold components and freeze-sensitive medicines unless specifically approved.

Close and seal the carton, record component lots, pack time and logger ID, and apply the required healthcare or dangerous-goods marks. Performance depends on the complete configuration, حمولة, تكييف, الملف الشخصي المحيط والتعامل معها. Qualify representative loads before routine use and manage changes through the buyer's quality system.

سمات

  • Protected VIP insulation with temperature-specific PCM panels.
  • Configurable 2–8 °C, 15–25 °C and sub-zero programs.
  • Custom payload chamber, data-logger location and operator packout controls.
  • Samples and technical inputs for buyer qualification.

طلب دعم الحزمة

  • Required product temperature range and permitted excursion limits
  • أبعاد الحمولة, وزن, units per shipment and minimum or maximum loads
  • Desired usable chamber volume and outer courier-size limits
  • وقت العبور, أصل, وجهة, route handoffs and summer or winter ambient profile
  • Preferred qualification target, مثل 48, 72, 96 أو 120 ساعات
  • PCM conditioning facilities and warehouse packout process
  • مسجل درجة الحرارة, probe position and shipment-record requirements
  • الاحتواء الثانوي, أدلة التلاعب, تسميات, مطبعة, samples and annual volume

التعليمات

What is a VIP-PCM pharmaceutical parcel shipper?

It is a passive temperature-controlled packaging system combining vacuum insulation panels with phase change materials. VIPs limit heat transfer, while conditioned PCMs absorb or release heat near a selected phase-change point.

Can one shipper cover 2–8 °C, 15–25 °C and frozen products?

Each temperature program needs its own PCM selection, كمية, conditioning procedure and qualified packout. A 2–8 °C configuration should not be assumed suitable for controlled room temperature or frozen products.

How long will the shipper maintain temperature?

Duration cannot be assigned to an empty box. Tempk can develop targets of 48, 72, 96 أو 120 ساعات, but results apply only to the tested payload, تكييف, component layout, الملف الشخصي المحيط والتعامل معها.

How should the PCM panels be conditioned?

Follow the approved procedure for the selected PCM. وقت, temperature and any tempering step must be controlled and recorded; visual appearance alone is not a release check.

Why must vacuum insulation panels be protected?

الثقوب, cuts or damaged edges can admit air and reduce insulation performance. Keep each panel in its protective frame and never cut or fold it during packing.

Can Tempk support pharmaceutical qualification work?

Tempk can provide samples, مواصفات المكونات, مخططات الحزمة, conditioning instructions and technical inputs. Final approval applies to the exact tested system under the buyer's quality process.

Can the shipper travel by air?

It can be developed for air lanes, but the sender or consignor must confirm airline and carrier requirements, الوثائق, labels and applicable dangerous-goods rules. The packaging configuration alone does not provide transport approval.

Is the VIP-PCM shipper reusable?

Reuse depends on the construction and the buyer's cleaning, تقتيش, return and change-control process. Corrugated parts, PCM packs and VIP assemblies may have different replacement criteria.
