Recyclable paper-fiber insulated shipping box with molded fiber liner

Tempk corrugated insulated shipper range

Recyclable Paper-Fiber Insulated Shipping Box

A corrugated parcel shipper with removable molded paper-fiber insulation for chilled food, kits de comida, fresh produce and temperature-sensitive e-commerce deliveries. Tempk configures the carton, fiber panels and coolant layout around the payload and route.

Formato del producto Corrugated outer carton with removable molded paper-fiber insulation
Common planning sizes 5-25 L inner-volume parcel formats; custom dimensions available
Insulation planning 25-40 mm paper-fiber panels; final thickness matched to the route
Compatible con refrigerante Paquetes de gel acondicionado, PCM packs and ice bricks

A paper-fiber shipper built around the complete packout

This paper-dominant insulated shipper combines a protective corrugated carton with fitted fiber panels that can be separated after use. It gives packing teams a practical alternative to rigid foam for parcel cadena de frío programs while keeping dimensions, espesor de aislamiento, moisture control and coolant placement open for project-specific design.

Paper-dominant construction

The corrugated carton and molded fiber insulation create a paper-based format with components that are straightforward to separate after use.

Protective fitted panels

Molded fiber panels support the carton walls, cushion the payload area and help reduce open thermal gaps around the lid and corners.

Flexible thermal design

Grosor del panel, internal volume and coolant placement can be adjusted instead of forcing different products into one fixed packout.

Practical packing workflow

Removable panels, a separate lid and a familiar corrugated closure make the system easy to stage and pack on parcel fulfillment lines.

Custom print and sizing

Tempk puede igualar las dimensiones del cartón, board strength, printing and internal components to the buyer's payload and shipping process.

Guía clara de eliminación

Project-specific material and disposal marks can help recipients separate clean, dry paper components according to local collection rules.

Detalles del producto

Marca Tempk
Nombre del producto Recyclable Paper-Fiber Insulated Shipping Box
Outer container Corrugated kraft shipping carton; board grade selected for payload weight and handling conditions
Aislamiento Removable molded paper-fiber side panels, base and lid
Typical inner-volume planning 5-25 L parcel formats; menor, larger and dimension-specific designs are available
Typical insulation thickness 25-40 mm planning range; final thickness is confirmed against the route and packout
Temperature programs Commonly configured for chilled 2-8°C or 0-10°C programs; frozen use requires a route-specific coolant and material review
Transit design target 24-48 hour parcel routes are a common starting point; the complete packout determines actual performance
Opciones de refrigerante Paquetes de gel acondicionado, PCM packs and ice bricks; dry ice only after reviewing material compatibility, desfogue, reglas de etiquetado y transporte
control de humedad Optional inner liner and absorbent pad for condensation, meltwater or liquid payload risks
Cierre Tape-sealed corrugated carton with route-specific handling labels
Personalización Dimensiones internas y externas, espesor del panel, board grade, impresión, divisores, coolant layout and packing quantity
Fin de vida Separate clean, dry paper components; actual recycling acceptance depends on coatings, contamination and local collection systems

Donde encaja mejor

Kits de comida y entrega de comestibles.

Packs chilled ingredients, prepared meals and grocery orders in a parcel format that is easy to stage at fulfillment centers.

Fresh produce and specialty food

Supports fruit, verduras, lácteos, panadería, confectionery and other products that need insulation from outdoor heat during delivery.

Chilled direct-to-consumer parcels

Gives subscription and e-commerce teams a customizable carton for repeat shipments with controlled coolant placement.

Regional wholesale distribution

Works for smaller B2B consignments moving between producers, cocinas, retailers and hospitality customers.

Sustainability-led packaging programs

Helps buyers evaluate a separable paper-dominant option when they want to reduce reliance on rigid foam components.

Cómo planificar el paquete

Definir el perfil de envío

Confirm payload dimensions and weight, temperatura objetivo, tiempo de tránsito, ambient exposure and delivery handoff.

Select the usable inner volume

Allow space for the product, refrigerante, divisores, liner and air-gap control before fixing the carton dimensions.

Condition payload and coolant

Pre-cool the product where appropriate and condition gel or PCM packs to the temperature required by the packout plan.

Control moisture and contact

Add a liner or absorbent pad when condensation or liquid is possible, and separate freeze-sensitive goods from direct coolant contact.

Load and close consistently

Fit all fiber panels, place coolant in the tested positions, install the lid and seal the corrugated carton with the specified tape pattern.

Validate the final system

Test with representative payload, masa refrigerante, ambient profile and transit handling before routine or high-value shipments.

Soporte de personalización

Carton dimensions and strength

Match internal clearance, outer parcel limits, peso de carga útil, stacking needs and the packing line.

Fiber panel design

Adjust panel thickness, densidad, ajuste de esquina, lid structure and component count around the route and storage plan.

Thermal packout

Select gel packs, PCM packs or ice bricks and define conditioning, quantity and placement for the target temperature window.

Moisture protection

Add a removable liner, absorbent layer or product separation where condensation and leakage risks require it.

Brand and handling print

Apply Tempk-supported custom colors, logo, guía de eliminación, packout instructions and shipping marks to the corrugated carton.

Supply format

Plan sample runs, bulk quantities, carton packing and component staging for the buyer's warehouse workflow.

Instrucciones de manejo

Store the corrugated cartons and paper-fiber insulation in a clean, dry area before packing. Keep fiber components away from direct water exposure unless the approved project specification includes suitable moisture protection.

Pre-condition the payload and coolant according to the packout plan. Install the base and side insulation completely, then position the product, refrigerante, dividers and any liner so that freeze-sensitive items do not touch frozen packs directly.

Fit the fiber lid without leaving large gaps and close the carton with the specified tape pattern. Apply perishable, orientation or temperature-handling labels required for the route.

The shipper provides insulation but does not create cooling by itself. Actual temperature duration depends on the full system, incluyendo carga útil, masa refrigerante, espesor del panel, ambient conditions and handling. Validate representative shipments before routine use.

If dry ice is being considered, confirm material compatibility, ventilación, dangerous-goods marking and carrier acceptance before use.

Características

  • Paper-dominant corrugated and molded-fiber construction.
  • Custom inner volume, panel thickness and coolant layout.
  • Optional moisture-control liner and absorbent components.
  • Designed for validated chilled parcel packouts.

Solicitar soporte para el paquete

  • Dimensiones de carga útil, weight and units per shipment
  • Target temperature range and acceptable product limits
  • Tiempo de tránsito, origen, destination and seasonal ambient exposure
  • Preferred inner volume, outer parcel limits and coolant type
  • Humedad, condensation and direct-contact restrictions
  • Carton print, cantidad de muestra, forecast volume and delivery schedule

Preguntas frecuentes

Is the complete insulated shipper recyclable?

The carton and molded fiber insulation are designed as separable paper-dominant components. Actual recycling acceptance depends on any coatings, adhesivos, food contamination and the collection rules at the destination, so Tempk confirms the project-specific material specification before a recycling claim is printed.

How long can it maintain a 2-8°C temperature range?

There is no single hold time for the empty box. Grosor del panel, masa de carga útil, tipo y cantidad de refrigerante, temperatura inicial, ambient profile and handling all affect performance. A 24-48 hour route is a common development starting point, followed by testing of the complete packout.

What sizes and insulation thicknesses are available?

Many parcel projects begin around 5-25 L of usable inner volume with approximately 25-40 mm fiber panels. Tempk can adjust the dimensions and panel structure after reviewing the payload, coolant and outer shipping limits.

Which coolants can be used?

Paquetes de gel acondicionado, PCM packs and ice bricks are common choices. The correct phase-change point, quantity and placement depend on the target temperature. Dry ice needs a separate material, ventilación, labeling and carrier review.

Can Tempk customize printing and packout components?

Sí. Tempk can support carton size and strength, fiber-panel design, printed branding, guía de eliminación, divisores, revestimiento, absorbent pads and a repeatable coolant layout.

Should the packout be tested before shipping?

Sí. Route testing with representative payload, refrigerante, ambient exposure and handling is recommended before routine use, especially for high-value, regulated or long-distance shipments.
