Leak-Resistant Seafood Shipping Box with EPS Liner

Tempk seafood cold-chain shipper

Leak-Resistant Seafood Shipping Box with EPS Liner

A corrugated seafood shipper with fitted EPS insulation and configurable secondary containment for chilled or frozen fish, Garnele, shellfish and other perishable seafood. Tempk entspricht der nutzbaren Kapazität, liner system, absorbent layer and coolant layout to the payload, Route, season and handling method.

Produktformat Corrugated outer carton with fitted EPS body and lid, plus configurable liner and absorbent components
Common usable payload volume 5–45 L Paketformate; custom dimensions are available
Common EPS wall thickness 25–60 mm as a project planning range
Temperaturprogramme Commonly developed around 0–4 °C for chilled seafood or −18 °C and below for frozen seafood

A seafood shipper built around temperature and moisture control

This shipper combines a protective corrugated carton, a fitted expanded-polystyrene body and lid, and a layered moisture-control packout. Sealed primary product bags provide the first barrier; an optional liner bag and absorbent material provide secondary containment for condensate, thaw water or accidental product leakage. The final design can be developed around chilled gel or PCM packs, gefrorenes Kühlmittel, wet ice where permitted, or a properly managed dry-ice packout.

Layered leak resistance

Sealed primary packs, an optional liner bag and correctly sized absorbent material work together to contain moisture inside the shipper.

Fitted EPS insulation

The close-fitting EPS body and lid reduce open joints around the payload cavity and provide a repeatable thermal envelope.

Chilled and frozen configurations

One product family can be developed for chilled seafood with conditioned gel or PCM packs and for frozen seafood with a suitable frozen refrigerant.

Protection for wet, schwere Nutzlasten

The outer carton grade, EPS density and closure can be selected around seafood weight, stacking and parcel-handling conditions.

Wiederholbarer Verpackungsworkflow

Defined product, absorbent and coolant positions help warehouse teams reproduce the intended packout from shipment to shipment.

Custom branding and supply

Tempk kann Abmessungen anpassen, Isolierung, Liner-Format, carton print and component kits for processors, Exporteure, distributors and fulfillment operations.

Produktdetails

Marke Tempk
Produktname Leak-Resistant Seafood Shipping Box with EPS Liner
Außenbehälter Versandkarton aus Wellpappe; single-wall or double-wall board selected for payload weight, stacking and route conditions
Isolierung Fitted expanded-polystyrene body with matching EPS lid
Common usable payload volume 5–45 L Paketformate; kleiner, larger and dimension-specific cavities are available
Common EPS wall thickness 25–60 mm planning range; final thickness depends on the temperature program, Strecke und Jahreszeit
Typische EPS-Dichteplanung Ungefähr 15–30 kg/m³, selected for mold strength, handling and thermal design
Indikative EPS-Wärmeleitfähigkeit Approximately 0.032–0.040 W/(m·K), abhängig von der Note, Dichte und Prüftemperatur
Gekühlte Programme Commonly configured around 0–4 °C with conditioned gel packs, PCM-Packungen oder Eissteine; the exact limit depends on the seafood and destination requirements
Eingefrorene Programme Commonly developed around −18 °C or below with an appropriate refrigerant and a pre-frozen payload
Ziel des Transitdesigns Overnight and 24–48-hour routes are common development starting points; longer or hotter lanes require a route-specific packout and testing
Primäre Eindämmung Seafood should remain in properly sealed, food-suitable product bags or trays
Sekundäre Eindämmung Optional LDPE or equivalent liner bag with a buyer-specified closure method
Saugfähige Schicht Optional pads or sheets sized to the expected condensate, thaw water and leakage risk
Kühlmitteloptionen Konditionierte Gelpackungen, PCM-Packungen und Eissteine; wet ice only where containment and carrier rules permit; dry ice only with ventilation, Trennung, Kennzeichnung und Carrier-Akzeptanz
Schließung Fitted EPS lid inside a tape-sealed or strapped corrugated carton with route-specific handling labels
Anpassung Innen- und Außenmaße, Wandstärke, Schaumdichte, Kartonqualität, Liner, Saugfähigkeit, Trenner, printing and coolant layout

Wo es am besten passt

Fresh and chilled fish

Supports whole fish, fillets and portion packs that need a controlled chilled distribution lane.

Shrimp and shellfish

Provides a configurable moisture-control packout for shrimp, prawns, Jakobsmuscheln, crab and other sealed shellfish products.

Gefrorene Meeresfrüchte

Can be developed around pre-frozen fish, shellfish and value-added seafood with a suitable frozen refrigerant.

Seafood processors and wholesalers

Offers repeatable component kits for packing plants, Märkte, Händler, restaurants and food-service buyers.

Export samples and premium parcels

Protects small wholesale samples, premium seafood orders and time-sensitive shipments moving by parcel or air freight.

Prepared seafood and meal kits

Supports sealed seafood portions, sauces and mixed chilled ingredients when each item is packed for its required temperature and leakage risk.

So planen Sie das Packout

Definieren Sie das Sendungsprofil

Confirm seafood type, chilled or frozen state, Nutzlastabmessungen und Gewicht, Temperaturgrenzen, Transitzeit, season and delivery handoff.

Pre-condition the payload and coolant

Chill or freeze the seafood before packing and condition gel, PCM, ice-brick or other refrigerant to the approved packout plan.

Seal the seafood first

Use intact, food-suitable primary bags or trays and verify every seal before loading the insulated cavity.

Install secondary containment

Fit the liner bag without punctures or trapped sharp edges, then add absorbent material in the planned position and quantity.

Load the payload and coolant

Keep the product stable, place refrigerant in the specified positions and prevent harmful direct contact or local freezing.

Close each packaging layer

Close the liner as specified, seat the EPS lid fully and seal or strap the corrugated carton using the defined pattern.

Label and document the shipment

Bewerben Sie sich verderblich, Orientierung, temperature or dangerous-goods information required by the product, carrier and route.

Testen Sie die komplette Verpackung

Evaluate representative payload, Kühlmittelmasse, Umgebungseinflüsse, leakage risk and handling before routine shipping.

Anpassungsunterstützung

Innen- und Außenmaße

Match seafood packs, Einheiten pro Sendung, Kühlmittelspiel, courier limits and pallet or warehouse handling.

Körper und Deckel aus EPS

Wandstärke anpassen, Schaumdichte, Deckel passt, internal ribs and molded cavity around the required payload.

Moisture-control system

Select liner size and closure, absorbent type and capacity, dividers and protective layers for fins, shells or sharp pack edges.

Thermische Konfiguration

Define chilled or frozen conditions, Kühlmitteltyp, Konditionierung, Menge, placement and separation from the seafood.

Kartonstärke und Druck

Geben Sie die Plattensorte an, tape or strapping closure, brand graphics, packout diagrams and handling marks.

Lieferformat

Muster planen, Pilotmengen, bulk orders and component kits arranged for the buyer's packing line.

Handhabungshinweise

Kartons aufbewahren, EPS components, liners and absorbent materials in a clean, Trockenbereich. Vor dem Packen, inspect the carton and EPS for damage and check every liner for punctures, open seams or contamination.

Pre-chill or pre-freeze the seafood and condition the refrigerant according to the packout plan. Seafood should be sealed in food-suitable primary packaging before it enters the insulated shipper. Install the secondary liner without stretching it across sharp corners, then place the specified absorbent material.

Load the payload and coolant in the defined positions. Keep freeze-sensitive chilled seafood from direct contact with fully frozen packs. If wet ice is used, confirm that the liner, closure and outer package can contain meltwater and that the carrier accepts the method.

Trockeneis setzt Kohlendioxidgas frei. Eine Trockeneisverpackung darf nicht luftdicht sein und erfordert eine geeignete Belüftung, Produkttrennung, Schonender Umgang, Markierung, Dokumentation und aktuelle Carrier-Akzeptanz.

Schließen Sie den Liner, EPS lid and outer carton consistently. The empty box does not create or guarantee a temperature duration or leak-proof shipment. Validate the complete system with representative seafood, Kühlmittel, ambient exposure and handling before routine use.

Merkmale

  • Fitted EPS body and lid inside a corrugated shipping carton.
  • Configurable liner and absorbent system for moisture control.
  • Chilled gel-pack, PCM and qualified frozen configurations.
  • Benutzerdefinierte Abmessungen, carton print and repeatable component kits.

Packout-Unterstützung anfordern

  • Meeresfrüchte-Typ, primary package format and chilled or frozen state
  • Nutzlastabmessungen, Gewicht und Einheiten pro Sendung
  • Required product temperature limits and starting condition
  • Transitzeit, Herkunft, Ziel, season and transport mode
  • Bevorzugte Nutzkapazität, äußere Paketgrenzen und EPS-Wandstärke
  • Gel, PCM, ice-brick, wet-ice or dry-ice preference
  • Expected condensate, thaw-water and leakage-control requirements
  • Kartondruck, Probenmenge, prognostiziertes Volumen und Lieferplan

FAQ

What makes this seafood box leak-resistant?

Leak resistance comes from several layers: sealed primary seafood packaging, an intact secondary liner, saugfähiges Material, a fitted EPS container and consistent outer-carton closure. The finished packout should be checked for the expected liquid volume and handling orientation.

Is leak-resistant the same as leak-proof?

NEIN. Leak-resistant describes a design intended to reduce and contain leakage. Actual containment depends on the product bags, liner material and closure, Saugfähigkeit, packout quality and handling. A buyer should test the complete packed system before shipment.

What temperature should chilled or frozen seafood use?

Chilled seafood programs are commonly developed around 0–4 °C, while frozen seafood is commonly handled at −18 °C or below. The seafood species, Produktform, buyer specification and destination rules determine the final limits.

Can I use gel packs, wet ice or dry ice?

Gel or PCM packs are common for clean chilled packouts. Wet ice may be used only when meltwater can be contained and the carrier accepts it. Dry ice is generally used for frozen programs and requires ventilation, Trennung, Markierung, documentation and carrier acceptance.

How long can the box keep seafood cold?

There is no single duration for an empty shipper. Nutzlastmasse, Starttemperatur, Art und Menge des Kühlmittels, EPS thickness, Umgebungseinflüsse und Handhabung wirken sich alle auf die Leistung aus. Overnight and 24–48-hour lanes are common development starting points, followed by testing.

Welche EPS-Wandstärke soll ich wählen??

Many parcel projects begin within a 25–60 mm range. Short chilled routes may use a thinner wall, while long, hot or frozen routes may require thicker insulation and more refrigerant. Tempk selects a starting design after reviewing the shipment profile.

Does seafood touch the EPS or liner directly?

Seafood should normally remain in sealed, food-suitable primary packaging. Where a liner or other component may contact food, the required material declaration should be specified for the destination market.

Can this shipper be used for live seafood?

It is intended primarily for packed chilled or frozen seafood. Live aquatic shipments may need species-specific oxygen, Wasser, Temperatur, containment and carrier arrangements and should be developed as a separate packout.

Can Tempk provide custom sizes and printed cartons?

Ja. Tempk can adjust the usable cavity, EPS wall thickness and density, Kartonstärke, Liner, absorbierendes System, Trenner, coolant layout and printing, abhängig von Werkzeug- und Bestellanforderungen.

Should the completed seafood packout be tested?

Ja. Test representative seafood, Kühlmittelmasse, Ausgangsbedingung, Umgebungsprofil, Vibration, fallen, compression and leakage risk before routine, long-distance, air-freight or seasonal shipments.
