VIP-PCM Pharmaceutical Parcel Shipper

Open VIP-PCM pharmaceutical shipper with payload chamber and PCM panels

Tempk pharmaceutical passive shipper range

VIP-PCM Pharmaceutical Parcel Shipper

A passive temperature-controlled packaging system combining protected vacuum insulation panels (VIPs) with temperature-specific phase change materials (PCMs). Tempk configures the payload chamber, PCM-Phasenpunkt, conditioning method and packout sequence for pharmaceutical, biologic and clinical-supply lanes.

Produktformat Passive temperature-controlled parcel shipper with protected VIPs and conditioned PCMs

Common payload planning Approximately 3–30 L usable payload volume; custom chambers available

Temperature programs 2–8 ° C, 15–25 °C controlled room temperature (CRT) and sub-zero programs use separate qualified configurations

Duration targets 48, 72, 96 oder 120 hours can be evaluated against the defined lane profile

A lane-specific passive shipper for high-value healthcare parcels

Inside the corrugated carton, protected VIPs and conditioned PCM panels surround a defined payload cavity. Separate configurations can be developed for refrigerated, kontrollierte Raumtemperatur (CRT) or frozen transport. Qualified duration applies only to the tested payload, Konditionierungsverfahren, ambient profile and route.

More usable payload space

Protected VIPs provide high insulation with thinner walls than many conventional systems, preserving payload volume.

Temperature-specific PCM control

The PCM phase point and conditioning state are selected around the medicine's allowable temperature range.

Repeatable packout geometry

Dedicated PCM positions, a defined payload chamber and packing instructions help operators reproduce the tested configuration.

Seasonal protection

A balanced PCM arrangement can be developed for summer, winter or combined ambient profiles, including freeze-sensitive 2–8 °C products.

Qualification inputs

Tempk can support component specifications, Packout-Diagramme, Konditionierungsanweisungen, samples and testing inputs for the buyer's qualification program.

Produktdetails

Marke	Tempk
Produktname	VIP-PCM Pharmaceutical Parcel Shipper
Systemtyp	Passive temperature-controlled parcel shipper
Outer container	Corrugated shipping carton selected for payload weight, Stapelung, route handling and required print
Isolierung	Protected vacuum insulation panels arranged around the payload chamber; panel construction is selected by project
VIP thickness planning	Approximately 10–25 mm is a common project starting range; final thickness follows thermal and mechanical design
VIP conductivity reference	Centre-of-panel values can be about 0.004 W/(m·K); final design uses supplier-declared aged, edge-adjusted and assembly-level data
Thermal storage medium	Rigid or flexible PCM panels selected by phase-change point, heat capacity, form and conditioning requirement
Nutzbares Nutzlastvolumen	Approximately 3–30 L; custom smaller and larger configurations are available
Temperature programs	Separate configurations can be developed for 2–8 °C, 15–25 °C controlled room temperature (CRT) and sub-zero products; each uses its own PCM and conditioning procedure
Duration planning	Qualification targets of 48, 72, 96 oder 120 hours are available for evaluation; no duration applies until the complete packout is tested
Ambient profiles	Sommer, winter and combined route profiles selected from the buyer's lane risk and qualification protocol
Payload configurations	Minimum and maximum payload conditions defined for qualification and routine packout control
Temperaturüberwachung	Optional data-logger pocket, sensor-location guide and shipment record label
Interior options	Payload carton, Trenner, Dämpfung, secondary containment and tamper-evident features
Schließung	Defined lid orientation, carton tape pattern and optional security seal
Anpassung	Nutzlastabmessungen, VIP geometry, PCM phase point and mass, Konditionierungs-SOP, Drucken, Etiketten, logger location and kit packing
Qualifizierungsunterstützung	Samples and technical inputs can support design qualification, operational qualification and performance qualification (DQ/OQ/PQ), route studies or ISTA thermal testing. Approval remains specific to the tested configuration

Wo es am besten passt

Impfstoffe und Biologika

Supports passive parcel programs where temperature stability, freeze protection and documented packout control are required.

Specialty and temperature-sensitive medicines

Provides configurable 2–8 °C or 15–25 °C transport for high-value prescription products and specialty therapies.

Clinical-trial supplies

Helps standardize investigational-product shipments between depots, Websites, laboratories and authorized recipients.

Diagnostic reagents and test kits

Protects temperature-sensitive kits, controls and reagents within the limits defined by their manufacturer.

Pharmaceutical samples and stability materials

Provides a compact format for validated samples, retained materials and controlled transfers between facilities.

Laboratory and healthcare materials

Can be configured for permitted biological or diagnostic contents when the sender provides the required primary and secondary packaging and follows applicable dangerous-goods rules.

So planen Sie das Packout

Definieren Sie das Sendungsprofil

Bestätigen Sie die Produkttemperaturgrenzen, Nutzlastabmessungen und -masse, minimale und maximale Belastungen, Transitzeit, route handoffs and monitoring needs.

Select the qualified configuration

Use the specified carton, VIP set, PCM type and quantity, payload components and sensor position for the season and lane.

Condition the PCM

Follow the approved time and temperature process, including any required tempering step before loading.

Inspect and assemble

Check every VIP for damage, then install the base, frame and PCM panels in the documented orientation. Never cut, fold or puncture a VIP.

Load the payload and monitor

Place the conditioned product, secondary containment and data logger in their defined positions and control harmful voids.

Verschließen und beschriften

Fit the top components, close the carton with the specified tape or seal pattern and apply required labels.

Record and release

Document component lots, Konditionierung, pack time and logger details before release under the buyer's approved procedure.

Anpassungsunterstützung

Payload chamber

Match vial cartons, medicine packs, klinische Kits, payload mass and minimum or maximum load conditions.

VIP insulation layout

Adjust panel dimensions, Dicke, Kantenschutz, corner treatment and protective frame without cutting panels during packing.

PCM configuration

Select phase-change point, Plattenform, Menge, placement and conditioning instructions for the target range and ambient profile.

Packout controls

Add color coding, numbered components, Ladediagramme, sensor guides and shipment record labels for operator consistency.

Umverpackung

Specify corrugated board grade, drucken, Handhabungsspuren, Originalitätsverschluss, courier limits and return-shipping needs.

Qualification package

Plan prototypes, Komponentenspezifikationen, Testproben, Sommer- und Winterprofile, minimum and maximum loads and change-control information.

Handhabungshinweise

Store cartons, VIP assemblies and PCM components in a clean, trocken, controlled area. Vor dem Gebrauch, verify the system size and seasonal configuration, then inspect every VIP for punctures, Schnitte, crushed edges or loss of rigidity. Do not use a damaged panel.

Condition each PCM component according to the approved standard operating procedure. Control and record the required time, temperature and any tempering step; visual appearance alone does not confirm readiness.

Assemble the documented configuration. Keep PCM orientation, Nutzlastfreiheit, minimale und maximale Belastung, sekundäre Eindämmung, cushioning and data-logger position consistent with the tested packout. Prevent direct contact between very cold components and freeze-sensitive medicines unless specifically approved.

Close and seal the carton, record component lots, pack time and logger ID, and apply the required healthcare or dangerous-goods marks. Performance depends on the complete configuration, Nutzlast, Konditionierung, ambient profile and handling. Qualify representative loads before routine use and manage changes through the buyer's quality system.

Merkmale

Protected VIP insulation with temperature-specific PCM panels.
Configurable 2–8 °C, 15–25 °C and sub-zero programs.
Custom payload chamber, data-logger location and operator packout controls.
Samples and technical inputs for buyer qualification.

Packout-Unterstützung anfordern

Required product temperature range and permitted excursion limits
Nutzlastabmessungen, Gewicht, units per shipment and minimum or maximum loads
Desired usable chamber volume and outer courier-size limits
Transitzeit, Herkunft, Ziel, route handoffs and summer or winter ambient profile
Preferred qualification target, wie zum Beispiel 48, 72, 96 oder 120 Std.
PCM conditioning facilities and warehouse packout process
Temperaturlogger, probe position and shipment-record requirements
Sekundäre Eindämmung, Manipulationsnachweis, Etiketten, drucken, samples and annual volume

FAQ

What is a VIP-PCM pharmaceutical parcel shipper?

It is a passive temperature-controlled packaging system combining vacuum insulation panels with phase change materials. VIPs limit heat transfer, while conditioned PCMs absorb or release heat near a selected phase-change point.

Can one shipper cover 2–8 °C, 15–25 °C and frozen products?

Each temperature program needs its own PCM selection, Menge, conditioning procedure and qualified packout. A 2–8 °C configuration should not be assumed suitable for controlled room temperature or frozen products.

How long will the shipper maintain temperature?

Duration cannot be assigned to an empty box. Tempk can develop targets of 48, 72, 96 oder 120 Std., but results apply only to the tested payload, Konditionierung, component layout, ambient profile and handling.

How should the PCM panels be conditioned?

Follow the approved procedure for the selected PCM. Zeit, temperature and any tempering step must be controlled and recorded; visual appearance alone is not a release check.

Why must vacuum insulation panels be protected?

Punktionen, cuts or damaged edges can admit air and reduce insulation performance. Keep each panel in its protective frame and never cut or fold it during packing.

Can Tempk support pharmaceutical qualification work?

Tempk can provide samples, Komponentenspezifikationen, Packout-Diagramme, conditioning instructions and technical inputs. Final approval applies to the exact tested system under the buyer's quality process.

Can the shipper travel by air?

It can be developed for air lanes, but the sender or consignor must confirm airline and carrier requirements, Dokumentation, labels and applicable dangerous-goods rules. The packaging configuration alone does not provide transport approval.

Is the VIP-PCM shipper reusable?

Reuse depends on the construction and the buyer's cleaning, Inspektion, return and change-control process. Corrugated parts, PCM packs and VIP assemblies may have different replacement criteria.
